Barebone axial flux motor
WX FRAMELESS.
Flexible high-performance
FRAMELESS MOTOR FOR TIGHTER ROBOTIC INTEGRATION
The WX Frameless series is engineered to be the heart of your machine. By eliminating the housing and bearings, these axial flux motor kits allow for direct integration into your mechanical assembly, saving critical weight and space. Designed for applications requiring high dynamic response and precision, they deliver maximum power in the most compact footprint possible.
MOTOR TYPE:
Brushless synchronous axial flux motor
INTEGRATION:
Frameless
DRIVE COMPATIBILITY:
Standard 3-phase motor controllers
INGRESS PROTECTION:
-
SENSORS:
Built-in temperature sensor
TORQUE RANGE:
From 0.1 Nm to 5 Nm continuous
APPLICATIONS:
Robotics
Humanoids
HIGHLIGHT:
Incredibly torque dense and flexible
AVAILABILITY:
From Q4 2026
WxF-70x24 GT
Our first frameless motor prototype is currently in advanced in-house testing, where it is already delivering reliable performance data.
Outer Diameter:
70.0 mm
Axial Height:
23.7 mm
Voltage:
48 V
Operating Temperature:
-40 to 85 °C
Continuous Torque¹:
1.6 Nm
Peak Torque:
5.0 Nm
Speed:
2500 rpm
Motor Constant²:
362.1 mNm/sqrt(W)
¹ Continuous torque the torque the motor can deliver continuously without reaching a critical temperature. The stated value is based on an application heat dissipation of 9.3 W. If your system removes heat more effectively, the achievable continuous torque will be higher.
² Motor constant indicates how much torque the motor can produce for a given level of heat loss. The higher the motor constant, the more torque the motor can sustain before temperature becomes the limiting factor.
OTHER SIZES WILL Also BE AVAILABLE SOON
OUTER DIAMETER RANGE:
From 50.0 to 115.0 mm
MOTOR CONSTANT RANGES:
